RIGHT VIEW
MULTI UPLIFTING
DUMPING
Left View
Technical Specification
| Machine Weight | 1660 Kg. |
| Machine Dimension (L x W x H) | 2560 x 1630 x 2010 mm |
| Main Broom | 1219 mm |
| Side Broom | 558 mm |
| Sweeping Width | 1523 mm |
| Sweeping Productivity | 184000 sq.ft./hr. |
| Speed | 15 Km/hr |
| Hopper Dust Load Capacity | 450 Kg. |
| Hopper Emptying Height Up to | 1560 mm |
| Engine Power Output | 28.8 kw @ 3000 RPM |
| Driver Cabin | Roof Type |
| Operating System | Hydraulic |
General Steps of Operating Process of the Machine
- Start Machine.
- Side Broom Down and start for rounding.
- Main Broom Down and start for rounding.
- Start sweeping in area where dust need to collect with required speed.
- Hopper Uplift to empty and Dump hopper in dust container to empty all dust.
- After emptying the hopper, down the hopper.
- Stop rounding of Brooms and get them up
- Stop the Machine & Park at place if no need to sweep more
- Mitsubishi 35 HP 4 Cylinder Engine
- World Class Hydraulic Pump from Eaton
TECHNICAL NAMES
A Self Propelled Hydraulically operated Automotive Sweeper, Industrial Sweeper, Street Cleaning Machine, Road Sweeper
| Areas of Application: | |||||
|---|---|---|---|---|---|
| 1 | Warehouse and Distribution | 2 | Health Care Institution (Hospital’s ) | 3 | Railway Station |
| 4 | Multiplex And Theatre | 5 | Super markets | 6 | Pharmacy Companies |
| 7 | Garment Industries | 8 | Research Center | 9 | Stadium |
| 10 | High way Road Cleaning | 11 | Museum | 12 | Municipality |
| 13 | Corporate Office Building | 14 | Metro Cities | 15 | Government Admin Block |
| 16 | Airport and Aviation | 17 | Food and Beverage’s | 18 | Port |
| 19 | Mining and Construction | 20 | Large Public Sector | 21 | Petrochemical and oil Industries |
| 22 | Large Apartment | 23 | Temple and Religious Place | 24 | Court Compound |
| 25 | Public Garden | 26 | Zoo | 27 | Village Street |
| 28 | Tourist Place | 29 | Small Town | 30 | Nigams |
| 31 | Hotel’s | 32 | Manufacturing Organization | 33 | Trust and private Institutional Organization |
| 34 | Shopping Mall’s | 35 | Communicational Sector | 36 | Rice and Textiles Industries |
| 37 | Sugar Industries | 38 | Column Content | 39 | Street Cleaning |
| 40 | Water Park | 41 | Educational institution like (School and Universities) | ||
Main Features of the Machine Utilization:
Environmental Friendly One Person Operation and Maintenance Easy to Drive Utilizes efficient Fuel and oil Cost Efficient
